| OPERATIONAL |
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
1/2.8” CMOS |
| Lens |
2.8 mm, Fixed, F1.4 |
| Number of Pixels (H x V) |
3MP (2304 x 1296) |
| Minimum Illumination (Color/BW) |
Color: 0.002 Lux @ F1.6 B/W: 0 Lux IR ON |
| S/N Ratio |
55 dB |
| Electronic Shutter Speed |
1/3 to 1/1,00,000s |
| IR Distance |
40 Mtrs |
| IR Light Control |
Smart IR (Auto/Manual)/OFF |
| Day/Night |
Auto/Day/Night/Timing |
| Backlight Compensation |
WDR, HLC, BLC |
| Wide Dynamic Range |
130 dB |
| Noise Reduction |
2D/3D DNR |
| Electronic Image Stabilization |
Supported |
| G-Sensor |
Supported |
| Privacy Masking |
Off/On (5 Areas) |
| Defog |
Supported |
| Local Storage |
Micro SD/SDHC/SDXC card slot (2TB) |
| IR-Cut Filter |
Supported |
| White Balance |
Auto/Fixed Current/Manual |
| Gain Control |
0 ~ 100% |
| Angle of View (H x V) |
H:87.2° V:49.1° |
| Reset |
Supported |
| VIDEO |
| Video Compression |
H.265 HEVC/H.264/MJPEG, Smart Codec |
| Number of Video Streams |
4 |
| Resolution* |
Main Stream: 2304 x 1296/1920 x 1080/1280 x 720/704 x 576/640 x 480/352 x 288/320 x 240
Second Stream: 2304 x 1296/1920 x 1080/1280 x 720/704 x 576/640 x 480/352 x 288/320 x 240
Third Stream: 1920 x 1080/1280 x 720/704 x 576/640 x 480/352 x 288/320 x 240
Fourth Stream: 640 x 480/352 x 288/320 x 240 |
| Frame Rate* |
Main Stream: Max@50fps Second Stream: Max@50fps Third Stream: Max@50fps Fourth Stream: Max@50fps |
| Bit Rate |
100K ~ 6 Mbps |
| NETWORK |
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Microsoft Edge, Chrome |
| Supported OS |
Microsoft Windows 10, Windows 11 |
| Protocols** |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, RTSP/RTP/RTCP, IGMP/ Multicast, SMTP, SNMP, DHCP, NTP, DNS, DDNS, CoS, QoS, 802.1X, UPnP, mDNS(Bonjour), UDP, ICMP, ARP, TLS, SFTP |
| Interoperability |
ONVIF Profile S/G/T/M |
| Maximum Users Access |
10 Users |
| Security |
Firmware encrypted & Signed, SD card encryption, User account and password protection, HTTPS, IP Filter, Digest authentication, Device Certificate, TLS 1.2 & 1.3, Stream encryption, AES128/256, SSH/Telnet closed, PCIDSS com- pliance, Secure boot, Prevent brute-force attack, Audit User Access/System/Event log management |
| Languages Supported |
English, French, German, Italian, Japanese, Portuguese, Spanish |
| EVENTS/ANALYTICS |
| Video Analytics |
Motion Detection, Scene Change, Tamper Detection, Smart Motion, Smart Intrusion, Smart Loitering, Smart Line Crossing Detection, Unattended Object Detection, Missing Object Detection, People Counter, Queuing, Crowd Gathering, Heat Map, Face Detection |
| Event Type |
Analytics alarm, Disk alarm, Recording alarm, Tampering |
| Event Linkage |
Email, SD card recording, SFTP recording, NAS recording |
| Region of Interest |
6 |
| Event Notification |
HTTPS, HTTP, SMTP, ONVIF |
| ELECTRICAL |
| Power Supply |
DC12V, PoE (IEEE 802.3af)(Class 0) |
| Power Consumption (Max) |
9.6 W |
| MECHANICAL |
| Dimensions |
Ø140 × 113.5 mm (5.5 x 4.47) |
| Dome Diameter |
Ø99.1 mm (3.90”) |
| Product Weight |
0.81 kg (1.79 lb) |
| Package Weight |
1.06 kg (2.34 lb) |
| Body Material |
Aluminium + Polycarbonate |
| Color |
White (RAL9003) |
| DORI*** (EN62676-4 STANDARD) |
| Detect |
60.6 Mtrs |
| Observe |
24 Mtrs |
| Recognize |
12.1 Mtrs |
| Identify |
6.1 Mtrs |
*Refer to resolution-frame rate reference document for more details.
** Some development may be required in specific user cases to support some of these protocols in the field as they mature over time.
***The table is for reference only. The detection value is a theoretical value and may differ from the actual detection value. The distances within it are subject to actual
conditions including atmospheric conditions, target size, the installation site and more. |
| ENVIRONMENTAL |
| Operating Temperature |
-30°C ~ 60°C (-22°F ~ 140°F) (IR off) |
| Relative Humidity |
Less than 95 %, Non-condensing |
| Ingress Protection |
IP66, IP67 |
| Impact Resistance |
IK10 |
| Reliability |
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78, IEC 60068-2-11, IEC 60068-2-27, IEC 60068-2-64 |
| Gore Vent |
Supported |
| REGULATORY |
| Emissions |
FCC PART 15, CE (EN 55032), ICES-003 |
| Immunity |
CE (EN 55035) |
| Safety |
UL listed to UL/CSA 62368-1, BIS IS 13252 (Part 1)/IEC 69050-1 |
| Environment |
RoHS, REACH, WEEE |
| Cyber Security |
BIS ER, STQC |
| Country of Origin |
India |
|
