Add extra
clarity to your
surveillance measures
Bundled with the latest encoding technology to help reduce bandwidth usage, this stellar product range from the Honeywell MMS security portfolio is what you need for smart security at an economical price.

Performance Pro 5MP AHD Series

Add the much-needed depth to your surveillance infrastructure without overshooting your budget. Experience enhanced video and image resolution to get effective analysis of the security video feeds. Get greater flexibility with a wide range of, compatible formats including AHD/CVI/TVI/CVBS video output and more. Furthermore, you get the benchmarked Honeywell quality and reliability, at an affordable price

PRODUCT OFFERINGS

The Performance Pro 5MP AHD portfolio
Get unmatched quality at unbeatable prices along with Honeywell quality assurance.

HADC-5005PI

Honeywell IR Dome cameras allow for continuous HD performance over extended distances due to its 2.5 inch sensor that captures sharper images in a wide range of formats.

FEATURES
  • 5MP real time high resolution
  • CMOS progressive scan
  • True day/night capability
  • Minimum illumination: 0 Lux(IR ON)
  • TDN, AWB, AGC, Defog
  • 3.6mm & 2.8-12mm lens
  • IR distance: up to 30 meters
  • Power: 12VDC
  • Vandal resistant
  • Dual output AHD & CVBS
  • Specifications
  • Ordering Info
  • Resources
Model No. HADC-5005PI
System
Video Standard PAL/NTSC
Scanning System Progressive
Image Sensor 1/2.5 CMOS sensor
Resolution 5M
Number of Pixels 5M:2592*1944
Minimum Illumination 0.01Lux BW, 0 Lux IR
Video Output AHD BNC, CVBS terminal
Video Frame Rate 20 - 30 fps (PAL/NTSC)
RF Option Internal
Automatic Electronic Shutter AUTO, PAL:1/25 s ~ 1/10, 000 s NTSC: 1/30 s to 1/10, 000 s
Lens Type 3.6 mm
IR LEDS 14μ x 18 PCS
IR Illumination Distance Up to 20 M
SNR >50 dB
Day/Night Yes
Automatic Gain Control Auto
White Balance Auto / Manual
WDR Yes
Digital Noise Reduction Yes
OSD Yes
Electrical
Input Voltage DC12V±10%, 550mA
Power Consumption 6W ± 10%
Mechanical
Dimensions 93(W) x 74(H) mm
Weight 400 g
Construction Metal Housing
Connectors Video output: AHD BNC connector; CVBS terminal, Power input: 2.1 mm plug
Environmental
Operating Temperature -10℃ ~ +60℃
Relative Humidity 95% Max
IP Rating IP67
Regulatory
Certification CE
System Compatibility
Compatible DVR AHD DVR
Model No.
HADC-5005PI 1/2.5 CMOS Sensor, 5 MP AHD, TDN, DNR, DWDR, 3.6mm, IR Dome Camera , 12 VDC
Documentation Size Release Date File Type Download
Datasheet 700.65 KB 18.11.2021 pdf Download
