| OPERATIONAL |
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
Sony IMX334, 1/1.8 in |
| Sensor Size (H x V) |
7,68 mm x 4,32 mm |
| Number of Pixels (H x V) |
8 MP (3840 x 2160) |
| Minimum Illumination (Color/BW) |
Color: 0.005 Lux @F1.5, B/W: 0Lux @F1.5(IR on) |
| S/N Ratio |
>50 dB |
| Electronic Shutter Speed |
Exposure mode: manual
min exposure time: 1/32000-1/120 max exposure time: 1/25000-1 |
| IR Distance |
40 m |
| IR Light Control |
Smart IR (Auto/Manual 0-100%), External IR trigger by output |
| IR Light Number |
22 |
| Removable IR-Cut Filter |
Yes |
| Day/Night |
Auto/Day/Night/Schedule |
| Backlight Compensation |
WDR, HLC |
| White Balance |
Auto/Fixed Current/Manual |
| Gain Control |
| Wide Dynamic Range |
130 dB |
| Noise Reduction |
3D DNR |
| Lens |
Remote Focus, 3,6 mm to 11 mm, MFZ, P - IRIS, F1.5 ~ F2.8 |
| Angle Of View (H x V) |
H: 105° ~ 49°, V: 58° ~ 28° |
| Privacy Masking |
Off/On (5 areas) |
| Defog |
Support |
| Encryption Chipset |
Built-in FIPS 140-2 certified encryption chipset |
| Local Storage |
2 Micro SD/SDHC/SDXC card slot (up to 1 TB each), SD card encryption |
| Micro USB |
Support Wi-Fi dongle configuration |
| Alarm Inputs / Outputs |
1 In/1 Out |
| VIDEO |
| Smart Video Analytics (Built-in) |
Intrusion detection, loiter detection, line crossing, face detection, object left unattended, object removed, motion detection, tampering detection |
| Video Analytics (Addition- al license required) |
License plate recognition |
| Video Compression |
H.265 HEVC/H.264/MJPEG, Smart Codec |
| Resolution (16/9) |
Main stream: 3840x2160, 3264x1840, 2688x1520, 2592x1944, 2048x1536,
1920x1080, 1280x960, 1280x720, 800x600,
640x480, 640x360, 320x240
Sub stream: 1920x1080, 1280x720, 800x600, 640x480, 640x360, 320x240
Third stream: 1280x720, 800x600, 704x576, 640x480, 640x360, 320x240 |
| Number of Video Streams |
3 |
| Frame Rate |
30 fps (8 M mode), 60 fps (2 M mode) |
| Bit Rate |
16K to 80M bps |
| AUDIO |
| Audio Compression |
G.711a/G.711Mu/G.726 |
| Audio Stream |
Full duplex, simplex |
| Audio Interface |
Line in/out |
| NETWORK |
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Mozilla Firefox™, Chrome™, Microsoft® Edge™ |
| Supported OS |
Microsoft® Windows™ 10 |
| Protocols |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/ RTP/RTCP, IGMP/Multicast, SMTP, DHCP, NTP, DNS, DDNS, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS |
| Interoperability |
ONVIF Profile S/G/T/M |
| Maximum Users Access |
10 users |
| Security |
User account and password protection, HTTPS, IP filter, digest authentication, TLS1.2 only, stream encryption, AES128/256, SSH/Telnet closed, PCIDSS compliance, FIPS 140-2 certified chipset built-in, UL 2900-2-3, Security Level L3 |
| Languages Supported |
English, French, German, Italian, Japanese, Por- tuguese, Russian, Spanish, Traditional Chinese |
| EVENTS |
| Event type |
Video analytics, periodically, alarm input, system boot, recording notification |
| Event linkage |
Event notification using digital output, HTTP, e-mail and MicroSD card |
| Region Of Interest |
6 |
| ELECTRICAL |
| Power Supply |
AC24 V , PoE (IEEE 802.3af, Class 3) |
| Power Consumption (Max) |
13 W |
| MECHANICAL |
| Dimensions (D x D x H) |
147,9 mm x 147,9 mm x 124, 1 mm (5.82 in x |
| 5.82 in x 4.89 in) |
| Dome Diameter |
95,0 mm (3.74 in) |
| Product Weight |
1,08 kg (2.38 lb) |
| Package Weight |
2,14 kg (4.72 lb) |
| Body Material |
Metal (die casting aluminum with powder coating) |
| Color |
RAL 120-1 (Honeywell white) |
| ENVIRONMENTAL |
| Operating Temperature |
-40°C to +60°C (-40°F to +140°F) (65°C [145°F] 4 hours) |
| Relative Humidity |
90 %, non-condensing |
| Ingress Protection |
IP66/IP67/NEMA 4X |
| Impact Resistance |
IK10 |
| Heater |
Yes |
| Gore-Vent |
Yes |
| REGULATORY |
| AUDIO |
| Audio Compression |
G.711a/G.711Mu/G.726 |
| Emissions |
FCC PART 15, CE (EN 55032), comply with RCM |
| and UKCA |
| Immunity |
CE (EN 50130-4), comply with RCM and UKCA |
| Safety |
UL Listed to UL/CSA 62368-1, CE (EN 62368-1), UL/CSA 60950-22, CE (EN 60950-22), comply |
| with UKCA |
| RoHS |
CE (EN 50581), |
| UAE (Cabinet Decree No.10 of 2017) |
| Country of Origin |
Taiwan |
| SYSTEM COMPATIBILITY |
| Pro-Watch NVR |
Up to 256 IP channels RAID5/6 Enterprise NVR |
| Maxpro NVR PE |
Up to 128 IP channels RAID5/6 Enterprise NVR |
| Maxpro NVR SE |
Up to 64 IP channels system NVR |
| Maxpro NVR XE |
Up to 16 IP channels system NVR |
| Maxpro NVR Software |
Up to 128 IP channels recording software |
| Honeywell DVM |
Supported with Honeywell DVM R700.1 (and later maintenance releases) |
