| OPERATIONAL |
|
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
1/3” CMOS |
| Number Of Pixels (H x V) |
2560x1440 |
| Minimum Illumination (Color/BW) |
0.005 lux @F1.6, AGC ON; 0 lux with IR |
| S/N Ratio |
≥50db |
| Electronic Shutter Speed |
1/2s ~ 1/100,000s |
| IR Distance |
20 ~ 30 m |
| IR Light Control |
Smart IR (Auto/Manual)/OFF |
| Day/Night |
ICR |
| Backlight Compensation |
WDR, HLC, BLC |
| White Balance |
Auto/Indoor/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Wide Dynamic Range |
120dB |
| Noise Reduction |
3D DNR |
| Lens |
2.8~12mm@ F1.4 |
| Angle Of View |
H:92°~31°, V:48°~17.2° |
| Privacy Masking |
Off / On (4 Areas) |
| Local Storage |
Micro SD (up to 256 GB) |
| VIDEO |
|
| Video Compression |
Main stream: H.265 / H.264
Sub stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264 / MJPEG |
| Resolution |
4MP (2560 × 1440), 3MP (2304 × 1296),
1080P (1920 × 1080), 720P (1280 × 720), D1,
480× 240, CIF |
| Number of Video Streams |
3 |
| Frame Rate Main Stream |
60Hz: 4MP/3MP/1080P/720P(1~30fps);
50Hz: 4MP/3MP/1080P/720P(1~25fps) |
| Frame Rate Second Stream |
60Hz: 720P/D1/CIF (1~30fps);
50Hz: 720P/D1/CIF (1~25fps) |
| Frame Rate Third Stream |
60Hz: D1/480× 240/CIF (1~30fps);
50Hz: D1/480× 240/CIF(1~25fps) |
| Bit Rate |
64 Kbps ~ 8 Mbps |
| Ingress Protection |
IP67 |
| Impact Resistance |
IK10 |
| AUDIO |
|
| Audio Compression |
G.711A/G.711U |
| Audio Stream |
1-way |
| Audio Interface |
1CH audio input |
| NETWORK |
|
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Chrome/Edge |
| Supported OS |
Microsoft Windows 10 |
| Protocols* |
IPv4, IPv6, TCP / IP, UDP, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DNS, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPs, QoS, IGMP / Multicast, ICMP, ARP, TLS |
| Interoperability |
ONVIF Profile G/S/T |
| Maximum Users Access |
3 Users |
| Security |
User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, AES128/256, SSH / Telnet closed |
| Languages Supported |
English, Italian, Portuguese, Russian, Spanish(Mexico), Dutch, French, German, Polish, Japanese, Chinese, Korean |
| EVENTS / ANALYTICS |
|
| Built-in Video Analytics |
Motion Detection, Tampering, Intrusion, Object, Video Exception (scene change, video blur and video cast detection), line crossing detection and region intrusion detection |
| Region Of Interest |
8 |
| ELECTRICAL |
|
| Power Supply |
12VDC, PoE (IEEE 802.3af) (Class 3) |
| Power Consumption (Max) |
MAX 8W |
| MECHANICAL |
|
| Dimensions (D x D x H) |
Ø 217.8 mm × 80.5 mm × 80.3 mm (Ø 8.57 x 3.16 x 3.16) |
| Product Weight |
0.66 kg (1.45lb) |
| Package Weight |
0.76 kg (1.67lb) |
| Body Material |
Metal housing |
| ENVIRONMENTAL |
|
| Operating Temperature |
-30 °C ~ 60 °C (-22°F~140°F) |
| Relative Humidity |
Less than 90% (non-condensing) |
| REGULATORY |
|
| Emissions |
EN 55032, FCC PART 15 |
| Immunity |
EN 55035 |
| Safety |
IEC 60950-1, IS 13252(Part 1) |
| RoHS |
IEC 62321 |
| SYSTEM COMPATIBILITY |
|
| 20 Series NVR |
Integration with 20 Series NVR |
| 35 Series NVR |
Integration with 35 Series NVR |
|
